| 品牌：纤亿通 | 型号：CWDM1270-1610 | 接口类型：lc |
| 传输距离：40km | 发射波长：1270-1610nmnm |
Performance Specifications
Parameter | 4 Channel | 8 Channel | 16 Channel | ||||
Mux | Demux | Mux | Demux | Mux | Demux | ||
Channel Wavelength (nm) | 1270~1610 | ||||||
Center wavelength Accuracy (nm) | ±0.5 | ||||||
Channel Spacing (nm) | 20 | ||||||
Channel Passband (@-0.5dB bandwidth (nm) | >13 | ||||||
Insertion Loss (dB) | ≤1.6 | ≤2.5 | ≤4.5 | ||||
Channel Uniformity (dB) | ≤0.6 | ≤1.0 | ≤1.5 | ||||
Channel Ripple (dB) | 0.3 | ||||||
***lation (dB) | Adjacent | N/A | >30 | N/A | >30 | N/A | >30 |
Non-adjacent | N/A | >40 | N/A | >40 | N/A | >40 | |
Inertion Loss Temperature Sensitivity (dB/℃) | <0.005 | ||||||
Wavelength Temperature Shifting (nm/℃) | <0.002 | ||||||
Polarization Dependent Loss (dB) | <0.1 | ||||||
Polarization Mode Dispersion | <0.1 | ||||||
Directivity (dB) | >50 | ||||||
Return Loss（dB） | >45 | ||||||
Maximum Power Handling (mW) | 300 | ||||||
Opterating Temperature (℃) | -5~+75 | ||||||
Storage Temperature (℃) | -40~85 | ||||||
Package dimension (mm) | L100 x W80 x H10 | L142 x W102 x H14.5 | |||||
Above specification are for device without connector.
Ordering Information
CWDM | X | XX | X | XX | X | X | XX |
Channel Spacing | Number of Channels | Configuration | 1st Channel | Fiber Type | Fiber Length | In/Out Connector | |
C=CWDM Grid | 04=4 Channel 08=8 Channel 16=16 Channel 18=18 Channel N=N Channel | M=Mux D=Demux O=OADM | 27=1270nm …… 47=1470nm 49=1490nm …… 61=1610nm SS=special | 1=Bare fiber 2=900um loose tube 3=2mm Cable 4=3mm Cable | 1=1m 2=2m S=Specify | 0=None 1=FC/APC 2=FC/PC 3=SC/APC 4=SC/PC 5=ST 6=LC S=Specify |
